англ 90-135
問題一覧
1
. …an elongated shape slightly similar to a circle. It has no straight lines or corners. For example, the number zero (0).
An oval
2
…is a closed shape. It is categorized as a two-dimensional geometric shape that is round in structure. It does not have any lines or corners. For example, the wheel of a vehicle, pizza base, dartboard.
A circle
3
…is a closed 2-D shape that is formed by four sides. The length of each side is equal in measurement. For example, a chessboard and a carrom board.
A square
4
…a shape with three sides and is categorized as a two-dimensional geometric shape. For example, the shape of tangy nachos, one slice of cheese burst pizza.
A triangle
5
…has four sides. It is a two-dimensional geometric shape in which the length of the opposite sides is equal. For example, laptop screen, touchscreen mobile phones etc.
A rectangle
6
…a closed two-dimensional figure with three or more straight lines. For example, windows, and doors.
A polygon
7
… a closed three-dimensional geometric shape. It is made up of six squares. It has six faces. For example, a Rubik's cube, a ludo dice, or an ice cube.
A cube
8
… another three-dimensional shape that is formed using rectangles. For example, a duster, a book, a pencil box.
A cuboid
9
… a solid shape that is similar to a ball. It is a closed three-dimensional shape formed using a circular base. For example, football, basketball, etc.
A sphere
10
… a solid shape that has two flat ends of circular formation. It is a three-dimensional figure which is formed by folding a rectangle. For example, coldrinkcans, pool noodles, water bottles.
A cylinder
11
… a solid three-dimensional geometric shape with a flat base. The base is circular in shape. It has a pointed edge at the top called the apex. For example, ice-creamcone, clown hat, etc.
A cone
12
… any structure, open or closed, having a definite shape and properties made up of lines, curves, and points.
A geometric shape
13
A horizontal member of stone, concrete or wood provided to give support for the vertical members of a wooden window, is called?
Sill
14
When a heavy structure is to be constructed in sandy soil, the foundation used is?
pier foundation
15
A brick which is half as wide as a full brick, is called?
queen closer
16
The depth of arch is the?
perpendicular distance between the intrados and extrados
17
The sill in a wooden partition wall is the .......... wooden member?
lower horizontal
18
Which of the following statement is correct?
all of the above
19
The cement which is commonly used in all types of structures and require no special sideration, is called ?
normal setting cement
20
The foundation in a building is provided to?
all of the above
21
___________ area of building is the area of verandahs, passage, corridors, balconies, porches, etc.
Horizontal circulation area
22
A 'detailed master plan' in architectural drawings includes:
In-depth analysis of site topography
23
A 'site plan' with detailed representation provides information about:
Landscaping elements and utilities
24
Which architectural drawing typically showcases a cut-away view of a building's interior?
Section
25
An 'elevation' in architectural drawings provides information about:
The building's exterior view
26
A 'floor plan' with detailed representation includes information about:
Interior room layout and features
27
In architectural drawings, a 'section' provides details about:
Cut-away views of building's interior
28
Detailed architectural drawings often include information about:
Specific construction materials and techniques
29
A “detailed master plan” includes the representation of:
Site’s elevation changes
30
A 'section' drawing in architectural representation is often taken along which axis?
Vertical axis
31
An architectural drawing that provides information about the arrangement of rooms on each floor of a building is called a:
Floor plan
32
Which software is commonly used for creating and editing raster graphics such as images and photographs?
Photoshop
33
In architectural visualization, 'V-ray' is often used for:
Creating realistic renderings
34
Which software is known for its real-time rendering capabilities, allowing architects to visualize designs in a dynamic environment?
Lumion
35
The software 'Revit' is commonly used for:
Both 2D drafting and 3D modeling
36
In architectural design, 'SketchUp' is known for its user-friendly interface and is often used for:
3D modeling and visualization
37
In architectural visualization, 'V-ray' is often used to achieve realistic lighting and shading effects in:
3D models
38
A key feature of 'Lumion' is its ability to:
Produce real-time animations and visualizations
39
In a municipal set of architectural drawings, 'structural drawings' primarily include details about:
Foundation and building structure
40
The 'sanitation drawings' in a municipal architectural set provide information about:
Plumbing and sewage systems
41
In a municipal set of architectural drawings, 'electrical drawings' include details about:
Electrical wiring and fixtures
42
The 'general documents' included in a municipal set of architectural drawings typically comprise:
Supporting reports and relevant documents
43
Which set of architectural drawings provides detailed information about the load-bearing elements and structural design of the building?
Structural drawings
44
In a municipal architectural set, 'sanitation drawings' focus on:
Plumbing and sewage systems
45
Which drawings in a municipal set provide details about the placement and arrangement of electrical fixtures, outlets, and wiring?
Electrical drawings
46
What purpose do 'general documents' serve in a municipal set of architectural drawings?
Include supporting reports and important information
