elecronic

56問 • 1年前

vhivru

通報

問題一覧

Describes a concept or an idea using symbols

pictogram

A thin and flexible strand that conducts electricity.

Wire

The wire is made up of two things:

the copper (conductor of eletricity) and rubber outer layer (insulator)

Two or more wires that are connected together aka the splice

joined wire

Unconnected or seperated wires, typically wrapped by electrical tape so that the electricity cannot escape

wire not joined

To turn electricity on and off meaning that it controls the flow of electricity in a circuit

switch

A device that stored and provides electrical energy. Chemical energy gets turned into electrical energy.

Cell or battery.

Outlets or sockets, this uses AC where in the direction of the flow of electricity switches back and forth at regular intervals or cycles.

AC voltage source

Commonly used at household appliances as it can be easily transmitted at long distances

Commonly used in batteries

Is a glass object that prevents the electricity from escaping.

Bulb

Holds a bulb and provides light when a current passes through it.

Lamp

A coiled up wire that creates a magnetic field when electricity passes through it.

Inductor or solenoid

A component that limits the flow of an electric current in a circuit

resistir

A type of resistor that is used to adjust the level of electric flow in a circuit. An example of it is a dimmer switch on a light fixture.

Rheostat

It is used to measure an unknown voltage by comparing it to the known voltage. It is also a type of resistor that has 3 terminals.

Potentiometer

In a potentiometer, There is a component that moves a wiper along a resistive element. This movement changes the resistance and voltage in a circuit. Moreover, it is commonly used to adjust volume in audio devices or settings in electronics.

knob/slider

It temporarily stores electrical energy. It consists if 2 plates separated by an insulator that resists electricity. It collects and holds the charge which can be then released when needed.

Capacitor

It allows the electricity to flow easily in one direction but restricts it to flow in other directions. This component uses DC.

Diode

A small electric device that lights up when electricity flows through it. It’s described to be energy efficient and can last a long time. This is also a type of Diode.

LED, light emitting diode

A device that converts sound waves to electronic signals. It is used to amplify or record voices. Additionally, it has no vibrating cone.

microphone

Small devices that you put into your ears to listen to sounds. It works by receiving an electrical signal from a device in which it can convert it into sound that you can hear.

earphones

It plays sound loudly. It converts sound waves to electrical signals. It has a vibrating cone or diaphragm which pushes air to create sound.

loudspeaker

It makes sound louder. It works by taking a small electrical signal and boosting its strength so it can drive a loudspeaker and produce louder sounds.

Amplifier

A device that changes the voltage of electricity on an AC

transformer

Safety device that operates to produce protection against the overflow of electrical circuits

fuse

A device that measures the voltage

Voltmeter

A device that measures the electric current

ammeter

A tool that measures the electrical resistance

ohm meter

a device that controls the flow of electricity in a circuit, acting as a switch or amplifier.

transistor

device that converts electrical energy into mechanical energy to create motion. It is commonly used to power machines and appliances.

motor

wire

joined wires

wires not joined

switch

cell/battery

AC voltage source

lamp

inductor/solenoid

resistor

rheostat

potentiometer

capacitor

diode

LED or light emitting diode

microphone

earphone

loudspeaker

amplifier

transformer

fuse

volt meter

ammeter

ohm meter

transistor

motor
